Features |
• SFP MSA SFF-8074i Compliant |
• SFP+ MSA SFF-8431/8432 Compliant |
• Ethernet IEEE 802.3-2002 Compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Single 3.3V Supply |
• Commercial and Industrial Temp. Operation |
|
|
 |
|
| |
| Fast Ethernet |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-FE-FX |
100Base-FX |
FP1310 |
PIN |
MMF 2km |
non-DDM version is available (-N) |
Datasheet |
SFP-FE-LX10 |
100Base-LX10 |
FP1310 |
PIN |
SMF 10km |
non-DDM version is available (-N) |
Datasheet |
SFP-FE-LX40 |
100Base-LX40 |
FP1310 |
PIN |
SMF 40km |
non-DDM version is available (-N) |
Datasheet |
SFP-FE-ZX80 |
100Bass-ZX80 |
DFB1550 |
PIN |
SMF 80km |
|
Datasheet |
|
| |
| Gigabit Ethernet |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-GE-SX |
1000Base-SX |
VCSEL850 |
PIN |
MMF 550m |
non-DDM version is available (-N) |
Datasheet |
SFP-GE-LXM |
1000Base-LXM |
FP1310 |
PIN |
MMF 2km |
non-DDM version is available (-N) |
Datasheet |
SFP-GE-LX |
1000Base-LX |
FP1310 |
PIN |
SMF 5km |
non-DDM version is available (-N) |
Datasheet |
SFP-GE-LX10 |
1000Base-LX10 |
FP1310 |
PIN |
SMF 10km |
non-DDM version is available (-N) |
Datasheet |
SFP-GE-LX20 |
1000Base-LX20 |
FP1310 |
PIN |
SMF 20km |
non-DDM version is available (-N) |
Datasheet |
SFP-GE-LX40 |
1000Base-LX40 |
DFB1310 |
PIN |
SMF 40km |
|
Datasheet |
SFP-GE-ZX60 |
1000Base-ZX60 |
DFB1550 |
PIN |
SMF 60km |
|
Datasheet |
SFP-GE-ZX80 |
1000Base-ZX80 |
DFB1550 |
PIN |
SMF 80km |
|
Datasheet |
|
| |
| 10G Ethernet |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP+10G-SR |
10GBase-SR |
VCSEL850 |
PIN |
OM3 300m |
|
Datasheet |
SFP+10G-LR |
10GBase-LR |
DFB1310 |
PIN |
SMF 10km |
|
Datasheet |
|
| |
| Single Fiber |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-FE-BX10-D |
100Base-BX10-D |
FP1550 |
PIN1310 |
SMF 10km |
|
Datasheet |
SFP-FE-BX10-U |
100Base-BX10-U |
FP1310 |
PIN1550 |
SMF 10km |
|
Datasheet |
SFP-GE-BX10-D |
1000Base-BX10-D |
DFB1490 |
PIN1310 |
SMF 10km |
Non-standard TX DFB1550 is available |
|
SFP-GE-BX10-U |
1000Base-BX10-U |
FP1310 |
PIN1490 |
SMF 10km |
Non-standard RX PIN1550 is available |
|
|
|
| |
|
 |
Features |
• SFP MSA SFF-8074i Compliant |
• Fiber Channel Physical Interface-4 Compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Single 3.3V Supply |
• Commercial and Industrial Temp. Operation |
|
|
|
|
| |
| 4XFC |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-4F-MM |
400-Mx-SN-I |
VCSEL850 |
PIN |
OM1 70m
OM2 150m
OM3 300m |
4/2/1G Fiber Channel |
Datasheet |
SFP-4F-SM10 |
400-SM-LC-L |
DFB1310 |
PIN |
OS1/2 10km |
4/2/1G Fiber Channel |
Datasheet |
|
| |
| 8XFC |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP+8F-MM |
800-Mx-SN-I |
VCSEL850 |
PIN |
OM1 21m
OM2 50m
OM3 150m |
8/4/2 G Fiber Channel |
Datasheet |
SFP+8F-SM10 |
800-SM-LC-L |
DFB1310 |
PIN |
OS1/2 10km |
8/4/2 G Fiber Channel |
Datasheet |
|
|
| |
|
 |
Features |
• SFP MSA SFF-8074i Compliant |
• GR 253/STM G.957 compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Single 3.3V Supply |
• Commercial and Industrial Temp. Operation |
|
|
|
|
| |
| OC-3 |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-OC3-IR1 |
OC-3 IR1 |
FP1310 |
PIN |
SMF 15km |
non-DDM version is available (-N) |
Datasheet |
SFP-OC3-LR1 |
OC-3 LR1 |
FP1310 |
PIN |
SMF 40km |
non-DDM version is available (-N) |
Datasheet |
SFP-OC3-LR2 |
OC-3 LR2 |
DFB1550 |
PIN |
SMF 80km |
non-DDM version is available (-N) |
Datasheet |
|
| |
| OC-12 |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-OC12-IR1 |
OC-12 IR1 |
FP1310 |
PIN |
SMF 15km |
non-DDM version is available (-N) |
Datasheet |
SFP-OC12-LR1 |
OC-12 LR1 |
DFB1310 |
PIN |
SMF 40km |
non-DDM version is available (-N) |
Datasheet |
SFP-OC12-LR2 |
OC-12 LR2 |
DFB1550 |
PIN |
SMF 80km |
non-DDM version is available (-N) |
Datasheet |
|
| |
| OC-48 |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
SFP-OC48-SR1 |
OC-48 SR1 |
FP1310 |
PIN |
SMF 2km |
|
Datasheet |
SFP-OC48-IR1 |
OC-48 IR1 |
DFB1310 |
PIN |
SMF 15km |
|
Datasheet |
SFP-OC48-IR2 |
OC-48 IR2 |
DFB1310 |
APD |
SMF 40km |
|
Datasheet |
SFP-OC48-LR1 |
OC-48 LR1 |
DFB1550 |
PIN |
SMF 40km |
|
Datasheet |
SFP-OC48-LR2 |
OC-48 LR2 |
DFB1550 |
APD |
SMF 80km |
|
Datasheet |
|
|
| |
|
 |
Features |
• XENPAK MSA INF-8474 Compliant |
• IEEE802.3ae 10G Ethernet compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Commercial Operation |
• 70 pin connector with XAUI interface |
|
|
 |
|
| |
| XENPAK |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
XENPAK-10G-CX4 |
10GBase-CX4 |
|
|
IF 20m |
|
Datasheet |
XENPAK-10G-LRM |
10GBase-LRM |
FP1310 |
PIN |
OM1 220m |
|
Datasheet |
XENPAK-10G-LX4 |
10GBase-LX4 |
|
|
OM1 300m |
|
Datasheet |
XENPAK-10G-SR |
10GBase-SR |
VCSEL850 |
PIN |
OM3 300m |
|
Datasheet |
XENPAK-10G-LR |
10GBase-LR |
DFB1310 |
PIN |
SMF 10km |
|
Datasheet |
XENPAK-10G-ER |
10GBase-ER |
EML1550 |
PIN |
SMF 40km |
|
Datasheet |
XENPAK-10G-ZR |
10GBase-ZR |
EML1550 |
APD |
SMF 80km |
|
Datasheet |
XENPAK-10G-DWDM |
10GBase-DWDM |
DWDM |
APD |
SMF 80km |
|
Datasheet |
|
|
| |
|
 |
Features |
• X2 MSA INF-8476i Compliant |
• IEEE802.3ae 10G Ethernet compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Commercial Operation |
• 70 pin connector with XAUI interface |
|
|
 |
|
| |
| XENPAK |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
X2-10G-CX4 |
10GBase-CX4 |
|
|
IF 20m |
|
Datasheet |
X2-10G-LRM |
10GBase-LRM |
FP1310 |
PIN |
OM1 220m |
|
Datasheet |
X2-10G-LX4 |
10GBase-LX4 |
|
|
OM1 300m |
|
Datasheet |
X2-10G-SR |
10GBase-SR |
VCSEL850 |
PIN |
OM3 300m |
|
Datasheet |
X2-10G-LR |
10GBase-LR |
DFB1310 |
PIN |
SMF 10km |
|
Datasheet |
X2-10G-ER |
10GBase-ER |
EML1550 |
PIN |
SMF 40km |
|
Datasheet |
X2-10G-ZR |
10GBase-ZR |
EML1550 |
APD |
SMF 80km |
|
Datasheet |
|
|
| |
|
 |
Features |
• XFP2 MSA INF-8077i Compliant |
• IEEE802.3ae 10G Ethernet compliant |
• Digital Diagnostic SFF-8472 Compliant |
• RoHS compliant |
• Commercial Operation |
• 70 pin connector with XAUI interface |
|
|
 |
|
| |
| XENPAK |
Product |
Application |
TX |
RX |
Reach |
Remark |
|
XFP-10G-SR |
10GBase-SR |
VCSEL850 |
PIN |
OM3 300m |
|
Datasheet |
XFP-10G-LR |
10GBase-LR |
DFB1310 |
PIN |
SMF 10km |
|
Datasheet |
XFP-10G-ER |
10GBase-ER |
EML1550 |
PIN |
SMF 40km |
|
Datasheet |
XFP-10G-ZR |
10GBase-ZR |
EML1550 |
APD |
SMF 80km |
|
Datasheet |
|
| |
| |
|
